STC15F2K60S2单片机8x8x8光立方原理图程序,元件清单

[复制链接]

电梯直达

楼主

ID:674815发表于 2020-11-28 10:32|只看该作者|只看大图回帖奖励

电路原理图如下：

元件清单:
名称   数量   规格/型号   备注
万能板   3   18*30cm
单片机STC15F2K60S2   1   DIP40   除非你会改程序，否则请勿擅自更换
74hc154   4       宽窄两种封装均可
40P  IC座   1
24P  IC座   4
电解电容47uF   1
104电容   1
拨动开关   1
铜柱（含螺母）   4   M3*100mm
灯珠   540   2*5*7mm雾状   颜色自选
弯排针   1   每组40P
直排针   8   每组40P
白色飞线   2   若干
USB转TTL下载器   1       PL2303系列或CH340系列
母对母杜邦线   3   每组40P
母对公杜邦线   1   每组40P
微动开关   1

单片机源程序如下:

/*作者：风铃 */
#include"STC15F2K60S2.h"
#include"intrins.h"
#include"basic.h"
#define SET 0x00
#define CLR 0x00
#define Segs P0
#define Out P1
sbit Rest=P3^0;
void IO_int();
void Timer1Init(void);
Byte code table[]={
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
0xff,0xff,0xff,0xff,0xff,0xff,0xff,0xff,
};
Byte code Segs_tab[]={
0xe0,0xe1,0xe2,0xe3,0xe4,0xe5,0xe6,0xe7,0xe8,0xe9,0xea,0xeb,0xec,0xed,0xee,0xef,
0xd0,0xd1,0xd2,0xd3,0xd4,0xd5,0xd6,0xd7,0xd8,0xd9,0xda,0xdb,0xdc,0xdd,0xde,0xdf,
0xb0,0xb1,0xb2,0xb3,0xb4,0xb5,0xb6,0xb7,0xb8,0xb9,0xba,0xbb,0xbc,0xbd,0xbe,0xbf,
0x70,0x71,0x72,0x73,0x74,0x75,0x76,0x77,0x78,0x79,0x7a,0x7b,0x7c,0x7d,0x7e,0x7f,
};
void Timer0Init(void);
unsigned char Anm1=0;
unsigned int End,Anm=0;
void main()
{
EA=1;
End=sizeof(table);
IO_int();
Timer0Init();
while(1)
{
if(Rest==0)IAP_CONTR=0x60;
if(Anm>End)Anm=0;
Segs=Segs_tab[Anm1];
Out=table[Anm1+Anm];
}
}
void IO_int()
{
P0M1=0x00;
P0M0=0x00;
P1M1=0x00;
P1M0=0xff;
}
void Timer0Init(void) //100微秒@22.1184MHz
{
AUXR |= 0x80; //定时器时钟1T模式
TMOD& = 0xF0; //设置定时器模式
TL0 = 0x5C; //设置定时初值
TH0 = 0xF7; //设置定时初值
TF0 = 0; //清除TF0标志
ET0=1;
TR0 = 1; //定时器0开始计时
}
void delay() interrupt 1
{
TR0=0;
Anm1=Anm1+1;
if(Anm1>63)Anm1=0;
Out=CLR;
Segs=0xff;
TR0=1;
}
